metal high head on off button switch 16mm 1no1nc ip67 momentary made in china
▶On off button switch product description:
Versatile Mounting
Featuring a standardized 16mm mounting hole, our switch seamlessly integrates into your setups, offering hassle-free installation and compatibility across a wide range of equipment and systems.
Robust Performance
Rated at 5A/250V, this switch delivers reliable performance, ensuring smooth operation and consistent functionality even under demanding conditions. Its IP67 waterproof rating guarantees protection against water ingress, making it suitable for both indoor and outdoor use.
Flexible Contact Configuration
With a 1NO1NC contact type and pin terminal contact terminals, this switch provides versatile options for wiring configurations, enabling seamless integration into your control circuits with ease.
Intuitive Operation
Available in both momentary and latching types of operation, our switch caters to your specific needs, whether it's for temporary activation or maintaining a steady state.
Durable Construction
Crafted from high-quality stainless steel, the shell of our switch is built to withstand the rigors of daily use, ensuring longevity and reliability in diverse environments.
Enhanced Visibility
Equipped with a high head design, this switch offers enhanced visibility and tactile feedback, facilitating easy operation even in low-light conditions. The absence of LED further streamlines the design, focusing on simplicity and functionality.
Elevate your control experience with our 16mm On Off Button Switch. Whether it's for industrial machinery, automotive applications, or consumer electronics, trust in our switch to deliver unparalleled performance and convenience. Experience the difference today!
▶On off button switch product model specification:
▶On off button switch product size:
▶On off button switch technical parameter:
|
16mm high head on off button switch |
|
| Product model : | HBDS1-AGQ16H-11(Z)/J/S |
| Mounting hole size : | 16MM |
| Switch value: | Ith:5A,UI:250V |
| Operation type: | Momentary,Latching |
| Contact configuration: | 1NO1NC |
| Appearance material: | Head:Stainless steel; Switch button surface:Stainless steel; Pedestal: PBT; Contact:Silver alloy; |
| Terminal type: | Pin terminal |
| Working environment temperature: | -25℃～+65℃ |
| Movement stroke: | About 3.2mm |
| Connection form: | Supporting connector/Welding wire |
| Rated current: | ≤20mA |
| Protection grade: | IP67 |
| Contact resistance: | ≤50mΩ |
| Insulation resistance: | ≥100MΩ |
| Electrical resistance: | AC2500V, 1min, no flicker and breakdown |
| Life | |
| Electrical part: Operate 50,000 times under rated load without any abnormality | |
| Mechanical part: No abnormal movement for 1000,000 times | |
